TuberÃa Estructural
| Producto | Nominal | Pulgadas | Milimetros | Fracc-pulgadas | Milesimas-pulgadas | Cedula | Peso-lb | Peso-kg-m | Largo | Peso | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Tuberia Estructural | ||||||||||||
 | tuberia est 6-3/16 | 6 | 6 5/8 | 4.78 | 3/16 | 0.188 | 40 | 12.92 | 19.35 | 6 | 116.1 | |
| tuberia est 6-7/32 | 6 | 6 5/8 | 5.60 | 7/32 | 0.219 | 40 | 14.98 | 22.47 | 6 | 134.82 | |
| tuberia est 6-1/4 | 6 | 6 5/8 | 6.35 | 1/4 | 0.250 | 40 | 17.02 | 25.55 | 6 | 153.3 | |
| tuberia est 6-9/32 | 6 | 6 5/8 | 7.10 | 9/32 | 0.280 | 40 | 18.97 | 28.22 | 6 | 169.32 | |
| tuberia est 6-3/8 | 6 | 6 5/8 | 9.50 | 3/8 | 0.375 | 40 | 24.99 | 37.20 | 6 | 223.2 | |
| tuberia est 8-3/16 | 8 | 8 5/8 | 4.78 | 3/16 | 0.188 | 10 | 16.94 | 25.37 | 6 | 152.22 | |
| tuberia est 8-7/32 | 8 | 8 5/8 | 5.60 | 7/32 | 0.219 | 20 | 19.66 | 29.48 | 6 | 176.88 | |
| tuberia est 8-1/4 | 8 | 8 5/8 | 6.35 | 1/4 | 0.250 | 20 | 22.36 | 33.57 | 6 | 201.42 | |
| tuberia est 8-5/16 | 8 | 8 5/8 | 7.90 | 5/16 | 0.312 | 30 | 27.70 | 41.14 | 6 | 246.84 | |
| tuberia est 8 | 8 | 8 5/8 | 8.20 | vacio | 0.322 | 40 | 28.55 | 42.65 | 6 | 255.90 | |
| tuberia est 8-3/8 | 8 | 8 5/8 | 9.50 | 3/8 | 0.375 | 40 | 33.04 | 49.10 | 6 | 294.60 | |
| tuberia est 8-1/2 | 8 | 8 5/8 | 12.70 | 1/2 | 0.500 | 80 | 43.99 | 65.47 | 6 | 392.82 | |
| tuberia est 10-3/16 | 10 | 10 3/4 | 273.1 | 3/16 | 0.188 | 4.78 | 10 | 21.21 | 31.76 | 6 | 190.56 |
| tuberia est 10-7/32 | 10 | 10 3/4 | 273.1 | 7/32 | 0.219 | 5.60 | 10 | 24.63 | 36.94 | 6 | 221.64 |
| tuberia est 10-vacio1 | 10 | 10 3/4 | 273.1 | vacio | 0.225 | 5.72 | 10 | 24.66 | 36.69 | 6 | 220.14 |
| tuberia est 10-1/4 | 10 | 10 3/4 | 273.1 | 1/4 | 0.250 | 6.35 | 20 | 28.04 | 42.09 | 6 | 252.54 |
| tuberia est 10-vacio2 | 10 | 10 3/4 | 273.1 | vacio | 0.307 | 7.80 | 30 | 24.24 | 51.03 | 6 | 306.18 |
| tuberia est 10-vacio3 | 10 | 10 3/4 | 273.1 | vacio | 0.365 | 9.27 | 40 | 40.48 | 60.50 | 6 | 363 |
| tuberia est 10-3/8 | 10 | 10 3/4 | 273.1 | 3/8 | 0.375 | 9.50 | 40 | 41.10 | 61.16 | 6 | 366.96 |
| tuberia est 10-1/2 | 10 | 10 3/4 | 273.1 | 1/2 | 0.500 | 12.70 | 60 | 54.80 | 81.55 | 6 | 489.3 |
| tuberia est 12-3/16 | 12 | 12 3/4 | 4.78 | 3/16 | 0.188 | 10 | 25.22 | 37.77 | 6 | 226.62 | |
| tuberia est 12-7/32 | 12 | 12 3/4 | 5.60 | 7/32 | 0.219 | 10 | 29.31 | 43.96 | 6 | 263.76 | |
| tuberia est 12-vacio | 12 | 12 3/4 | 5.72 | vacio | 0.225 | 10 | 30.30 | 45.09 | 6 | 270.54 | |
| tuberia est 12-1/4 | 12 | 12 3/4 | 6.35 | 1/4 | 0.250 | 20 | 33.38 | 50.11 | 6 | 300.66 | |
| tuberia est 12-3/8 | 12 | 12 3/4 | 9.50 | 3/8 | 0.375 | ced std | 49.56 | 73.65 | 6 | 441.9 | |
| tuberia est 12-13/32 | 12 | 12 3/4 | 10.30 | 13/32 | 0.406 | 40 | 53.52 | 79.65 | 6 | 477.9 | |
| tuberia est 14-vacio1 | 14 | 14 | 5.30 | vacio | 0.210 | 10 | 30.93 | 45.78 | 6 | 274.68 | |
| tuberia est 14-vacio2 | 14 | 14 | 5.72 | vacio | 0.225 | 10 | 32.68 | 48.63 | 6 | 291.78 | |
| tuberia est 14-1/4 | 14 | 14 | 6.35 | 1/4 | 0.250 | 10 | 36.71 | 55.11 | 6 | 330.66 | |
| tuberia est 14-5/16 | 14 | 14 | 7.90 | 5/16 | 0.312 | 20 | 45.61 | 67.74 | 6 | 406.44 | |
| tuberia est 14-3/8 | 14 | 14 | 9.50 | 3/8 | 0.375 | 30 | 54.57 | 81.08 | 6 | 486.48 | |
| tuberia est 14-vacio3 | 14 | 14 | 11.10 | vacio | 0.438 | 40 | 63.44 | 94.30 | 6 | 565.8 | |
| tuberia est 14-vacio4 | 14 | 14 | 11.81 | vacio | 0.465 | 40 | 67.87 | 101.00 | 6 | 606 | |
| tuberia est 14-1/2 | 14 | 14 | 12.70 | 1/2 | 0.500 | ext fte | 72.09 | 107.39 | 6 | 644.34 | |
| tuberia est 16-7/32 | 16 | 16 | 5.60 | 7/32 | 0.219 | 10 | 36.91 | 55.35 | 6 | 332.1 | |
| tuberia est 16-vacio | 16 | 16 | 5.72 | vacio | 0.225 | 10 | 37.28 | 55.48 | 6 | 332.88 | |
| tuberia est 16-1/4 | 16 | 16 | 6.35 | 1/4 | 0.250 | 10 | 42.05 | 63.13 | 6 | 378.78 | |
| tuberia est 16-vacio1 | 16 | 16 | 7.14 | vacio | 0.281 | 20 | 47.17 | 69.91 | 6 | 419.46 | |
| tuberia est 16-5/16 | 16 | 16 | 7.90 | 5/16 | 0.312 | 20 | 52.27 | 77.63 | 6 | 465.78 | |
| tuberia est 16-3/8 | 16 | 16 | 9.50 | 3/8 | 0.375 | 30 | 62.58 | 92.98 | 6 | 557.88 | |
| tuberia est 16-1/2 | 16 | 16 | 12.70 | 1/2 | 0.500 | 40 | 82.77 | 123.30 | 6 | 739.8 | |
| tuberia est 18-1/4 | 18 | 18 | 6.35 | 1/4 | 0.250 | 10 | 47.39 | 71.12 | 6 | 426.72 | |
| tuberia est 18-5/16 | 18 | 18 | 7.90 | 5/16 | 0.312 | 20 | 58.94 | 87.49 | 6 | 524.94 | |
| tuberia est 18-3/8 | 18 | 18 | 9.50 | 3/8 | 0.375 | ced std | 70.59 | 104.84 | 6 | 629.04 | |
| tuberia est 18-1/2 | 18 | 18 | 12.70 | 1/2 | 0.500 | ext fte | 93.45 | 139.15 | 6 | 834.9 | |
| tuberia est 20-1/4 | 20 | 20 | 6.35 | 1/4 | 0.250 | 10 | 52.73 | 79.16 | 6 | 474.96 | |
| tuberia est 20-5/16 | 20 | 20 | 7.90 | 5/16 | 0.312 | 20 | 65.60 | 97.43 | 6 | 584.58 | |
| tuberia est 20-3/8 | 20 | 20 | 9.50 | 3/8 | 0.375 | 20 | 78.60 | 116.78 | 6 | 700.68 | |
| tuberia est 20-1/2 | 20 | 20 | 12.70 | 1/2 | 0.500 | 30 | 104.13 | 155.12 | 6 | 930.72 | |
| tuberia est 24-1/4 | 24 | 24 | 9.50 | 1/4 | 0.375 | 20 | 94.62 | 140.68 | 6 | 844.08 | |
| tuberia est 24-3/8 | 24 | 24 | 9.50 | 3/8 | 0.375 | 20 | 94.62 | 140.68 | 6 | 844.08 | |
| tuberia est 24/1/2 | 24 | 24 | 12.70 | 1/2 | 0.500 | ext fte | 125.49 | 187.06 | 6 | 1122.36 | |
| tuberia est 30 | 30 | 30 | 6.35 | 1/4 | 0.250 | 5 | 79.43 | 119.25 | 6 | 715.5 | |
| tuberia est 30-3/8 | 30 | 30 | 9.50 | 3/8 | 0.375 | ced std | 118.65 | 176.29 | 6 | 1057.74 | |
| tuberia est 30-1/2 | 30 | 30 | 12.70 | 1/2 | 0.500 | ext fte | 157.53 | 234.67 | 6 | 1408.02 | |
| tuberia est 32-1/4 | 32 | 32 | 6.35 | 1/4 | 0.250 | 5 | 84.77 | 127.30 | 6 | 763.8 | |
| tuberia est 32-3/8 | 32 | 32 | 9.50 | 3/8 | 0.375 | ced std | 126.66 | 188.24 | 6 | 1129.44 | |
| tuberia est 32-1/2 | 32 | 32 | 12.70 | 1/2 | 0.500 | ext fte | 168.21 | 250.64 | 6 | 1503.84 | |
| tuberia est 36-5/16 | 36 | 36 | 7.90 | 5/16 | 0.312 | 10 | 118.92 | 176.52 | 6 | 1059.12 | |
| tuberia est 36-3/8 | 36 | 36 | 9.50 | 3/8 | 0.375 | ced std | 142.68 | 211.90 | 6 | 1271.4 | |
| tuberia est 36-1/2 | 36 | 36 | 12.70 | 1/2 | 0.500 | ext fte | 189.57 | 282.27 | 6 | 1693.62 | |
| Tuberia Estructural 6 | ||||||||||||
| tuberia est 6-3/16 | 6 | 6 5/8 | 4.78 | 3/16 | 0.188 | 40 | 12.92 | 19.35 | 6 | 116.1 | |
| tuberia est 6-7/32 | 6 | 6 5/8 | 5.60 | 7/32 | 0.219 | 40 | 14.98 | 22.47 | 6 | 134.82 | |
| tuberia est 6-1/4 | 6 | 6 5/8 | 6.35 | 1/4 | 0.250 | 40 | 17.02 | 25.55 | 6 | 153.3 | |
| tuberia est 6-9/32 | 6 | 6 5/8 | 7.10 | 9/32 | 0.280 | 40 | 18.97 | 28.22 | 6 | 169.32 | |
| tuberia est 6-3/8 | 6 | 6 5/8 | 9.50 | 3/8 | 0.375 | 40 | 24.99 | 37.20 | 6 | 223.2 | |
| Tuberia Estructural 8 | ||||||||||||
| tuberia est 8-3/16 | 8 | 8 5/8 | 4.78 | 3/16 | 0.188 | 10 | 16.94 | 25.37 | 6 | 152.22 | |
| tuberia est 8-7/32 | 8 | 8 5/8 | 5.60 | 7/32 | 0.219 | 20 | 19.66 | 29.48 | 6 | 176.88 | |
| tuberia est 8-1/4 | 8 | 8 5/8 | 6.35 | 1/4 | 0.250 | 20 | 22.36 | 33.57 | 6 | 201.42 | |
| tuberia est 8-5/16 | 8 | 8 5/8 | 7.90 | 5/16 | 0.312 | 30 | 27.70 | 41.14 | 6 | 246.84 | |
| tuberia est 8 | 8 | 8 5/8 | 8.20 | vacio | 0.322 | 40 | 28.55 | 42.65 | 6 | 255.90 | |
| tuberia est 8-3/8 | 8 | 8 5/8 | 9.50 | 3/8 | 0.375 | 40 | 33.04 | 49.10 | 6 | 294.60 | |
| tuberia est 8-1/2 | 8 | 8 5/8 | 12.70 | 1/2 | 0.500 | 80 | 43.99 | 65.47 | 6 | 392.82 | |
| Tuberia Estructural 10 | ||||||||||||
| tuberia est 10-3/16 | 10 | 10 3/4 | 273.1 | 3/16 | 0.188 | 4.78 | 10 | 21.21 | 31.76 | 6 | 190.56 |
| tuberia est 10-7/32 | 10 | 10 3/4 | 273.1 | 7/32 | 0.219 | 5.60 | 10 | 24.63 | 36.94 | 6 | 221.64 |
| tuberia est 10-vacio1 | 10 | 10 3/4 | 273.1 | vacio | 0.225 | 5.72 | 10 | 24.66 | 36.69 | 6 | 220.14 |
| tuberia est 10-1/4 | 10 | 10 3/4 | 273.1 | 1/4 | 0.250 | 6.35 | 20 | 28.04 | 42.09 | 6 | 252.54 |
| tuberia est 10-vacio2 | 10 | 10 3/4 | 273.1 | vacio | 0.307 | 7.80 | 30 | 24.24 | 51.03 | 6 | 306.18 |
| tuberia est 10-vacio3 | 10 | 10 3/4 | 273.1 | vacio | 0.365 | 9.27 | 40 | 40.48 | 60.50 | 6 | 363 |
| tuberia est 10-3/8 | 10 | 10 3/4 | 273.1 | 3/8 | 0.375 | 9.50 | 40 | 41.10 | 61.16 | 6 | 366.96 |
| tuberia est 10-1/2 | 10 | 10 3/4 | 273.1 | 1/2 | 0.500 | 12.70 | 60 | 54.80 | 81.55 | 6 | 489.3 |
| Tuberia Estructural 12 | ||||||||||||
| tuberia est 12-3/16 | 12 | 12 3/4 | 4.78 | 3/16 | 0.188 | 10 | 25.22 | 37.77 | 6 | 226.62 | |
| tuberia est 12-7/32 | 12 | 12 3/4 | 5.60 | 7/32 | 0.219 | 10 | 29.31 | 43.96 | 6 | 263.76 | |
| tuberia est 12-vacio | 12 | 12 3/4 | 5.72 | vacio | 0.225 | 10 | 30.30 | 45.09 | 6 | 270.54 | |
| tuberia est 12-1/4 | 12 | 12 3/4 | 6.35 | 1/4 | 0.250 | 20 | 33.38 | 50.11 | 6 | 300.66 | |
| tuberia est 12-3/8 | 12 | 12 3/4 | 9.50 | 3/8 | 0.375 | ced std | 49.56 | 73.65 | 6 | 441.9 | |
| tuberia est 12-13/32 | 12 | 12 3/4 | 10.30 | 13/32 | 0.406 | 40 | 53.52 | 79.65 | 6 | 477.9 | |
| Tuberia Estructural 14 | ||||||||||||
| tuberia est 14-vacio1 | 14 | 14 | 5.30 | vacio | 0.210 | 10 | 30.93 | 45.78 | 6 | 274.68 | |
| tuberia est 14-vacio2 | 14 | 14 | 5.72 | vacio | 0.225 | 10 | 32.68 | 48.63 | 6 | 291.78 | |
| tuberia est 14-1/4 | 14 | 14 | 6.35 | 1/4 | 0.250 | 10 | 36.71 | 55.11 | 6 | 330.66 | |
| tuberia est 14-5/16 | 14 | 14 | 7.90 | 5/16 | 0.312 | 20 | 45.61 | 67.74 | 6 | 406.44 | |
| tuberia est 14-3/8 | 14 | 14 | 9.50 | 3/8 | 0.375 | 30 | 54.57 | 81.08 | 6 | 486.48 | |
| tuberia est 14-vacio3 | 14 | 14 | 11.10 | vacio | 0.438 | 40 | 63.44 | 94.30 | 6 | 565.8 | |
| tuberia est 14-vacio4 | 14 | 14 | 11.81 | vacio | 0.465 | 40 | 67.87 | 101.00 | 6 | 606 | |
| tuberia est 14-1/2 | 14 | 14 | 12.70 | 1/2 | 0.500 | ext fte | 72.09 | 107.39 | 6 | 644.34 | |
| Tuberia Estructural 16 | ||||||||||||
| tuberia est 16-7/32 | 16 | 16 | 5.60 | 7/32 | 0.219 | 10 | 36.91 | 55.35 | 6 | 332.1 | |
| tuberia est 16-vacio | 16 | 16 | 5.72 | vacio | 0.225 | 10 | 37.28 | 55.48 | 6 | 332.88 | |
| tuberia est 16-1/4 | 16 | 16 | 6.35 | 1/4 | 0.250 | 10 | 42.05 | 63.13 | 6 | 378.78 | |
| tuberia est 16-vacio1 | 16 | 16 | 7.14 | vacio | 0.281 | 20 | 47.17 | 69.91 | 6 | 419.46 | |
| tuberia est 16-5/16 | 16 | 16 | 7.90 | 5/16 | 0.312 | 20 | 52.27 | 77.63 | 6 | 465.78 | |
| tuberia est 16-3/8 | 16 | 16 | 9.50 | 3/8 | 0.375 | 30 | 62.58 | 92.98 | 6 | 557.88 | |
| tuberia est 16-1/2 | 16 | 16 | 12.70 | 1/2 | 0.500 | 40 | 82.77 | 123.30 | 6 | 739.8 | |
| Tuberia Estructural 18 | ||||||||||||
| tuberia est 18-1/4 | 18 | 18 | 6.35 | 1/4 | 0.250 | 10 | 47.39 | 71.12 | 6 | 426.72 | |
| tuberia est 18-5/16 | 18 | 18 | 7.90 | 5/16 | 0.312 | 20 | 58.94 | 87.49 | 6 | 524.94 | |
| tuberia est 18-3/8 | 18 | 18 | 9.50 | 3/8 | 0.375 | ced std | 70.59 | 104.84 | 6 | 629.04 | |
| tuberia est 18-1/2 | 18 | 18 | 12.70 | 1/2 | 0.500 | ext fte | 93.45 | 139.15 | 6 | 834.9 | |
| Tuberia Estructural 20 | ||||||||||||
| tuberia est 20-1/4 | 20 | 20 | 6.35 | 1/4 | 0.250 | 10 | 52.73 | 79.16 | 6 | 474.96 | |
| tuberia est 20-5/16 | 20 | 20 | 7.90 | 5/16 | 0.312 | 20 | 65.60 | 97.43 | 6 | 584.58 | |
| tuberia est 20-3/8 | 20 | 20 | 9.50 | 3/8 | 0.375 | 20 | 78.60 | 116.78 | 6 | 700.68 | |
| tuberia est 20-1/2 | 20 | 20 | 12.70 | 1/2 | 0.500 | 30 | 104.13 | 155.12 | 6 | 930.72 | |
| Tuberia Estructural 24 | ||||||||||||
| tuberia est 24-1/4 | 24 | 24 | 9.50 | 1/4 | 0.375 | 20 | 94.62 | 140.68 | 6 | 844.08 | |
| tuberia est 24-3/8 | 24 | 24 | 9.50 | 3/8 | 0.375 | 20 | 94.62 | 140.68 | 6 | 844.08 | |
| tuberia est 24/1/2 | 24 | 24 | 12.70 | 1/2 | 0.500 | ext fte | 125.49 | 187.06 | 6 | 1122.36 | |
| Tuberia Estructural 30 | ||||||||||||
| tuberia est 30 | 30 | 30 | 6.35 | 1/4 | 0.250 | 5 | 79.43 | 119.25 | 6 | 715.5 | |
| tuberia est 30-3/8 | 30 | 30 | 9.50 | 3/8 | 0.375 | ced std | 118.65 | 176.29 | 6 | 1057.74 | |
| tuberia est 30-1/2 | 30 | 30 | 12.70 | 1/2 | 0.500 | ext fte | 157.53 | 234.67 | 6 | 1408.02 | |
| Tuberia Estructural 32 | ||||||||||||
| tuberia est 32-1/4 | 32 | 32 | 6.35 | 1/4 | 0.250 | 5 | 84.77 | 127.30 | 6 | 763.8 | |
| tuberia est 32-3/8 | 32 | 32 | 9.50 | 3/8 | 0.375 | ced std | 126.66 | 188.24 | 6 | 1129.44 | |
| tuberia est 32-1/2 | 32 | 32 | 12.70 | 1/2 | 0.500 | ext fte | 168.21 | 250.64 | 6 | 1503.84 | |
| Tuberia Estructural 36 | ||||||||||||
| tuberia est 36-5/16 | 36 | 36 | 7.90 | 5/16 | 0.312 | 10 | 118.92 | 176.52 | 6 | 1059.12 | |
| tuberia est 36-3/8 | 36 | 36 | 9.50 | 3/8 | 0.375 | ced std | 142.68 | 211.90 | 6 | 1271.4 | |
| tuberia est 36-1/2 | 36 | 36 | 12.70 | 1/2 | 0.500 | ext fte | 189.57 | 282.27 | 6 | 1693.62 | |
